Product Details:
|
| Rated Current: | 5A (0.5mm2), 5A (0.75mm2), 8A (1mm2),10A (1.5mm2) | Rated Voltage: | 24V DC |
|---|---|---|---|
| Insulation Resistance: | ≥5000mΩ | Dielectric Withstanding Voltage: | 1000V AC |
| Wire Range: | 0.5 Mm2~1.5mm2 | IP Rating: | IP67 |
| Operation Temperature: | -40 ℃ ~+125 ℃ | Salt Spray Resistance: | 144H (mating State) |
| HVIL: | Yes | Shell: | Plastic |
| Angle: | Straight Angle | ||
| High Light: | 120A 2 pin plug and socket connectors,IP67 2 pin plug and socket connectors,IP67 waterproof plug and socket connector |
||
Bayonet Coupling
Helical Structure
Cable range: 0.5~1.5mm2
Poka-yoke
7 Core Connector
| Rated Current: | 5A (0.5mm2), 5A (0.75mm2), 8A (1mm2),10A (1.5mm2) |
| Rated Voltage: |
24V |
| Insulation Resistance: | ≥4000mΩ(power)≥1000mΩ(signal) |
| Dielectric Withstanding Voltage: | 3500V AC (power), 1000V AC(signal) |
| Temperature Range: | -40~+125 ℃ |
| IP Rating: | IP67&IP6K9K,IPXXB |
| Application: | Motor controller, battery, driving system, charging system |
S909-EV-S7P plug
S909-EV-P7R Receptacle
S909-EV-P7RA Receptacle
S909 7Pin Receptacle Mounting Interface Design
NeoPower is dedicated to high-voltage/ high-current waterproof connectors & cables, applicable for new energy battery pack, EV, heavy-duty machinery, industrial connection, powertrain system, solar/wind energy storage, smart grid, AGV, etc.
Neopower has two manufacture bases located in Huizhou, Guangzhou Province for plastic shell connectors, and in Changzhou, Jiangsu Province for metal shell connectors respectively. With rich expertise and high-standard management, Neopower delivers top quality products and excellent services to customers around the world.
The company has passed IATF 16949:2016, ISO 9001:2015 quality control system, and its products are CE, TVU, RoHs approved.
